RMILEC V3 18 High Precision Channel PWM PPM SBUS Signal Converter
£24.90
This is the latest generation of RMILEC’s high-precision PWM/PPM/SBus signal converter. The V3 has been designed to allow the user to convert an input PWM signal into a corresponding PPM / SBus signal output, or convert two-way PPM signal into PWM signals and SBUS signals, or alternatively convert the input SBUS signal into a corresponding two-way PPM signal and PWM signal output. Finally, it can be connected with a PC via a TTL-USB serial port to conduct PWM, PPM and SBUS signal analysis.
Features
- Mode 1 PWM Input: Converts the input PWM signal into a corresponding PPM signal and SBUS signal output.
- Mode 2 Two-way PPM Input: Converts the input PPM signal into a corresponding PWM signal and SBUS signal output.
- Mode 3 SBUS Input: Converts the input SBUS signal into a corresponding PPM signal and PWM signal output.
- Data Analyser Function
Specifications
- Input voltage: 3.3 ~ 12V
- Supports: Reverse polarity protection
- Precision: 250nanoseconds
- Signal Generator: Hardware anti interrupt program
- Weight: 8.5g
- Dimensions: 36 x 29 x 12mm
