RadioMaster R Series R84 V2 4 Channel Receiver – D8, D16 & SFHSS Compatible
RadioMaster R Series R84 V2 4 Channel Receiver – D8, D16 & SFHSS Compatible
RadioMaster R Series R84 V2 4 Channel Receiver – D8, D16 & SFHSS Compatible
RadioMaster R Series R84 V2 4 Channel Receiver – D8, D16 & SFHSS Compatible
RadioMaster R Series R84 V2 4 Channel Receiver – D8, D16 & SFHSS Compatible
RadioMaster R Series R84 V2 4 Channel Receiver – D8, D16 & SFHSS Compatible

RadioMaster R Series R84 V2 4 Channel Receiver – D8, D16 & SFHSS Compatible

£17.80

The RadioMaster R84 V2 is a lightweight 4-channel PWM receiver compatible with FrSky D8 , D16 , and Futaba SFHSS protocols via a multi-protocol radio. Designed for smaller aircraft and gliders, it offers a solid control range of over 1km along with fail-safe and RSSI output. At just 22×13×5mm and 2.2g, it’s ideal for compact builds where only a few channels are needed. Requires an external multi-protocol module for binding—does not work with FrSky internal RF systems.

RadioMaster R Series Receivers: There is a choice of 4 receivers to suit different applications. In addition to PWM channels, R86C & R88 both have SBUS connections and support RSSI. All feature dual antennas and are full range (>1km Control distance) with support for setting a failsafe.

Options:

R81 Receiver – SBUS

R84 – 4 PWM Channels

R86 – 6 PWM Channels

R86C – 6 PWM Channels / SBUS (8CH)

R88 – 8 PWM Channels / SBUS (8CH)

Frsky transmitter not supported, only for MPM radio.

Selecting protocol:

Once the receiver has been put into bind mode, it will then cycle between the 3 protocol options: D8, D16 (FCC V1) and S-FHSS:

Three singles flashes = D8 Protocol

Three double flashes = D16 Protocol

Three triple flashes = S-FHSS Protocol

Select Bind on your radio when the receiver reaches the matching protocol.

Associated Products

Replacement Antenna for R84 R86 R86C R88 Receiver

Specifications
