Matek Micro BEC 1.5A 6-30V Input – Output 5/9V (1pc)

£4.50

This voltage regulator is similar to the Matek 1.5A Mini BEC , the difference being this one can handle a wider input voltage 6-30V vs. 7-21V, and its output can be set at 5V or 9V, vs. 5V or 12V. The voltage output of this BEC is selected by a simple solder tab; by default it is set to output 5 volts, with the solder tabs connected it will output 9 volts.

Specifications

• Input Voltage Range: 6-30v
• Continuous load current: 1.5 Amps (Max.2.5A 5s/minute)
• Voltage Out: 5V or 9V Adj. Default is 5V.
• VOut Load Regulation: 2% Standby current: <5mA Maximum Duty Cycle: 95%
• OCP Protection and Hiccup
• Thermal Shutdown
• Output Short-circuit tolerant (5 seconds/minute)
• Pins distance: 2.54mm
• Size: 10x14x3mm
• Weight: 1g

In the box

• 1x Matek Step Down Micro BEC 5V/9V (1Pc)
